イメージャ デュアル ビュー 5.5 mm 直径 2 M

イメージャ デュアル ビュー 5.5 mm 直径 2 Mです。
Maximum Light Output Forward View Imager: 300 Lux; Side View Imager: 2 400 Lux at 1" (open air dissipation)
Length inches (mm) 78 47/64 (200)
Weight lb (kg) .75 (0.340)
Storage Temperature -4 to 158° F (-20 to 70° C)
Water Resistance Imager to a depth of 10' (3 m)
Humidity 5 to 100% non-condensing
Operating Temperature Range 32 to 113° F (0 to 45° C)
Dual View Imager 5.5 mm Diameter 2 M
Power Supply Forward View Imager: 100 mA; Side View Imager: 100 mA
Optimal Focal Range Forward View Imager: 1 to 12" (2.5 to 30 cm); Side View Imager: 1 to 12" (2.5 to 30 cm)
Lighting Forward View Imager: 4 mini-LEDs w/custom ring light pipe; Side View Imager: single LED with custom light pipe
Maximum Bend Radius 3/4" (19.05 mm)
Description (Chart) 36" Dual View Imager (5.5 mm head)
Width inches (mm) .2165 (5.5)
